GDS Renko Reversal Context Indicator Explained
Info
The GDS Renko Reversal Context Indicator Explained is a Indicator for MetaTrader 5 that gds renko reversal contextwhat it shows- current renko direction: up or down- number of consecutive confirmed bricks in the current run- fixed brick size- last confirmed renko close- price level where the opposite renko brick becomes confirmed- current market distance to that reversal level, measured in brickshow it worksthe indicator builds a small classic renko model directly from the symbol's tick history. Continuation rule:A new brick in the current direction is confirmed after price moves one full brick beyond the last Renko close.
Usage
This tool is typically used for enhancing chart analysis and decision making.
Platform
This Indicator works exclusively on MetaTrader 5 (both build 600+ and newer versions).
Setup
Place the downloaded file in MQL5/Indicators folder via File ? Open Data Folder in MetaTrader 5.
How to Install and Use GDS Renko Reversal Context Indicator Explained
1. Installation: Place your file in the MQL/Indicators folder via "Open Data Folder" and restart your terminal.
2. Loading: Find the indicator in the Navigator, drag it onto your chart, and configure the input parameters in the popup window.
3. Customization: Press Ctrl+I to open the indicator list, select your tool, and click "Properties" to change colors, levels, or visual styles.
4. Updating: Replace the old file in the Indicators folder with the new version and restart the platform to apply changes.
Frequently Asked Questions
Q: Why is my indicator not showing? A: Verify the file is in the MQL/Indicators folder, or try right-clicking the "Indicators" tree in the Navigator and clicking "Refresh."
Q: Do custom indicators slow down the platform? A: Too many complex indicators can impact performance; remove unused ones via the "Indicator List" (Ctrl+I).
Q: Can I use MT4 indicators on MT5? A: No, MQL4 and MQL5 are distinct languages; ensure the indicator is compiled specifically for your platform version.
What this tool does
GDS Renko Reversal ContextWhat it shows- Current Renko direction: UP or DOWN- Number of consecutive confirmed bricks in the current run- Fixed brick size- Last confirmed Renko close- Price level where the opposite Renko brick becomes confirmed- Current market distance to that reversal level, measured in bricksHow it worksThe indicator builds a small classic Renko model directly from the symbol's tick history.
Typical Use Case
This Indicator excels in automated trading and technical analysis on MetaTrader 5.
Compatible Platform & Setup
This Indicator works on MetaTrader 5. Place the file in the MQL5/Indicators folder and restart the terminal.
Description & Settings
Related: GDS Renko Liquidity Sweep Lab: Price Action Analysis - another powerful indicator for MetaTrader 5 traders.
GDS Renko Reversal ContextAlso recommended: GDS Renko Brick Statistics - similar indicator with strong performance on MetaTrader 5.
What it shows
- Current Renko direction: UP or DOWN
- Number of consecutive confirmed bricks in the current run
- Fixed brick size
- Last confirmed Renko close
- Price level where the opposite Renko brick becomes confirmed
- Current market distance to that reversal level, measured in bricks
How it works
The indicator builds a small classic Renko model directly from the symbol's tick history.
Continuation rule:
A new brick in the current direction is confirmed after price moves one full brick beyond the last Renko close.
Reversal rule:
A reversal is confirmed only after price moves two full brick sizes against the current direction.
For an UP run:
reversal = last Renko close - 2 * brick size
For a DOWN run:
reversal = last Renko close + 2 * brick size
The dashed horizontal line marks that level.
Why this indicator exists
A common Renko mistake is to treat every counter-move as a reversal. In classic Renko that is not true. Price must reach the two-brick reversal threshold before the opposite brick is confirmed.
This indicator is intentionally small. It does not generate BUY/SELL signals and does not try to predict the next brick. It only shows the current Renko context.
Inputs
InpBrickPoints Brick size in symbol points.
InpHistoryTicks Number of recent ticks used to initialize the Renko sequence.
InpShowReversalLine Show/hide the reversal level on the chart.
InpX / InpY Panel position from the upper-right chart corner.
Color inputs Display colors only.
Notes
- The source is self-contained: no external .mqh libraries are required.
- The sequence is built from Bid ticks when Bid is available; Last is used as fallback.
- Tick history availability depends on the broker/server and local MT5 history.
- This is an educational/context indicator, not a trading system.
Suggested screenshot
Use a clean XAUUSD chart with a 100- or 500-point brick size. Keep the panel visible in the upper-right corner and the dashed reversal level clearly visible on price.
Suggested CodeBase category
Indicators / Examples / Renko
You may also like: GDS Renko Canvas with Donchian Channel - excellent alternative for indicator users on MetaTrader 5.
Source Code
#property copyright "RobotFX"
#property link "https://robotfx.org"
#property version "1.01"
#property description "This code is educational. Feel free to use, modify and upgrade as you wish. Visit ROBOTFX.ORG for professional trading tools"
#property indicator_chart_window
#property indicator_plots 0
input group "Renko"
input double InpBrickSize = 1.00;
input int InpHistoryTicks = 100000;
input group "Display".......
