T5Copier - MT 5 client to client Local trade copier

Related: exp 3 parabolic - another powerful expert for MetaTrader 5 traders.

A local client to client trade copier with custom dashboard in C# and transport pipe in golang

How to Run the MT5 Trade Copier ( Archived dll based version )

Also recommended: long-only trend breakout ea with advanced risk management - similar expert with strong performance on MetaTrader 5.

Step 1: Start the ZMQ Routing Bridge

Open Windows File Explorer and navigate to:

C:\T5Copier\Go_bridge\

Double-click and run


T5Copier_Bridge.exe
.

A terminal window will open indicating that the bridge is listening on:

Port

5567

(Master incoming)

Port

5568

(Slave outgoing)

Port

5569

(Dashboard logs)

Step 2: Open the C# WPF Dashboard

Navigate to:

C:\T5Copier\Dashboard\

Double-click and run


CSharpDashboard.exe
.

In the dropdown at the top, select


MT5 Copier (Port 5569)
.

Click


Connect Dashboard
. The status indicator will change to

CONNECTED (MT5) .

Step 3: Set up the MT5 Master Terminal (Sender)

Open the MT5 terminal that you want to copy trades


from
.

Make sure the Master EA is installed: go to the Navigator panel, right-click


Experts
, and click


Refresh
. You should see

T5Copier_Master .

Drag

T5Copier_Master

onto


any single chart
.

In the properties window:

Go to the


Common


tab and check


Allow DLL imports


and


Allow Algo Trading
.

Go to the


Inputs


tab and ensure the address matches the bridge:

tcp://localhost:5567 .

Click


OK
. Ensure the


Algo Trading


button in the MT5 top toolbar is green.

Step 4: Set up MT5 Slave Terminals (Receivers)

Open one or more MT5 terminals that you want to copy trades


to
.

Drag the Slave EA ( T5Copier_Slave ) onto a chart.

In the properties window:

Go to the


Common


tab and check


Allow DLL imports


and


Allow Algo Trading
.

Go to the


Inputs


tab and configure your copy logic:

InpLotMode
: Select

LOT_MODE_FULL ,

LOT_MODE_RATIO , or

LOT_MODE_FIXED .

InpLotMultiplier
: Set your multiplier (e.g.,

2.0

for double lots).

InpReverseCopy
: Set to

true

if you want to flip BUYs to SELLs and vice versa.

Click


OK
. Ensure


Algo Trading


is enabled in the top toolbar.

++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

ere is the comprehensive step-by-step user guide for running the new trade copier versions.

Part 1: Running the MT5 DLL-Free Copier (Codebase Compliant)

This version uses MetaTrader 5's


native TCP sockets
, meaning it is


100% DLL-free


and does not require any external library files ( libzmq.dll

or

libsodium.dll ) to run or validate.

Step 1: Start the Go TCP Bridge

Navigate to:

C:\T5Copier\Go_bridge\

Double-click and run


T5Copier_Bridge.exe
.

A console window will open indicating that the Go Bridge is listening on TCP port


5580
.

Step 2: Launch the C# WPF Dashboard

Navigate to:

C:\T5Copier\Dashboard\

Double-click and run


CSharpDashboard.exe
.

In the dropdown, select


MT5 Copier (Port 5580)
.

Click


Connect Dashboard
. The status will change to

CONNECTED (MT5) .

Step 3: Attach the MT5 Master EA (Sender)

Open your Master MT5 terminal.

In the Navigator, drag


T5Copier_Master


onto any single chart.

In the properties window:

Common tab
: Ensure


Allow Algo Trading


is checked.


(Note: DLL imports are NOT required!)

Inputs tab
: Verify the server address is

127.0.0.1

and the port is

5580 .

Click


OK
. Enable


Algo Trading


in the MT5 top toolbar.

Step 4: Attach the MT5 Slave EA (Receiver)

Open your Slave MT5 terminal.

Drag


T5Copier_Slave


onto any chart.

In the properties window:

Common tab
: Check


Allow Algo Trading
.


(DLL imports are NOT required!)

Inputs tab
: Configure your preferred parameters (e.g.

InpLotMode ,

InpLotMultiplier ,

InpReverseCopy ).

Click


OK
. Enable


Algo Trading


in the toolbar.

Part 2: Running the MT4 Copier (ZeroMQ Powered)

This version uses the high-performance


ZeroMQ


library, which matches MT4's strict environment.

Step 1: Start the Go ZMQ Bridge

Navigate to:

C:\T4Copier\Go_bridge\

Double-click and run


T4Copier_Bridge.exe
.

It will listen on Ports:

5557

(Master incoming)

5558

(Slave outgoing)

5559

(Dashboard logs)

Step 2: Launch the C# WPF Dashboard

Navigate to:

C:\T4Copier\Dashboard\

Double-click and run


CSharpDashboard.exe
.

In the dropdown, select


MT4 Copier (Port 5559)
.

Click


Connect Dashboard
.

Step 3: Attach the MT4 Master EA (Sender)

Open your Master MT4 terminal.

Drag


T4Copier_Master


onto any chart.

In the properties window:

Common tab
: Check


Allow DLL imports
.


(Required for ZeroMQ DLLs!)

Inputs tab
: Keep the default

tcp://localhost:5557 .

Click


OK
.

Step 4: Attach the MT4 Slave EA (Receiver)

Open your Slave MT4 terminal.

Drag


T4Copier_Slave


onto any chart.

In the properties window:

Common tab
: Check


Allow DLL imports


and


Allow live trading
.

Inputs tab
: Set inputs (e.g.,

InpLotMode ,

InpLotMultiplier , etc.).

Click


OK
.

Step 5: Verification (Common to Both)

Place a trade on the Master terminal.

Watch the


C# Dashboard
: The trade details (ticket, symbol, type, lot size) will immediately pop up in the


Active Copied Trades


grid.

Confirm that the trade was replicated instantly on the Slave terminal(s) with your configured lot/reverse rules.

Close the trade on the Master terminal; the Slave terminal(s) will close it instantly.

You may also like: divergence trader - excellent alternative for expert users on MetaTrader 5.

#property copyright "RobotFX"
#property link "https://robotfx.org"
#property version   "1.00"
#include <Trade/Trade.mqh>
enum ENUM_LOT_MODE
  {
   LOT_MODE_FULL = 0,
   LOT_MODE_RATIO = 1,
   LOT_MODE_FIXED = 2
  };

.......
