Download MQ L5 Wizard - Trade Signals Based on Morning/Evening Stars + RS I for MetaTrader 5

The allows creating ready-made Expert Advisors based on the classes delivered together with the client terminal (see for the details). It allows to check your trade ideas quickly, all you need is to create your own trading signals class. The structure of this class and example can be found in the article .
The generic idea is the following: the class of trading signals is derived from , the next, it's necessary to override the and virtual methods with your own methods.
There is a book " (in Russian), there are many trading strategies are considered there, we will focus on reversal candlestick patterns, confirmed by , , and oscillators.
The best way is to create the separate class, derived from for checking of formation of candlestick patterns. For confirmation of trade signals, generated by candlestick patterns, it's sufficient to write the class, derived from CCandlePattern and add the necessary features (for example, confirmation by oscillators) there.
Here we will consider the signals, based on "Morning Star/Evening Star" (Morning Doji Star/Evening Doji Star) reversal candlestick patterns, confirmed by indicator. The module of trade signals is based on the class, it's simple example of its use for creation of trade signals with candlestick patterns.
1. "Morning Star" and "Evening Star" reversal candlestick patterns
1.1. Morning Star
This pattern indicates the reversal of downtrend, it consists of three candles (Fig. 1). After a long black candle there is a candle (the color isn't important) with a small body, which lies outside the body of the black candle. The small body of a candle means that strengths of the bulls and bears are equal and market is ready to change the trend.
The third candle of the pattern is the bullish candle, it's body isn't overlapped with the body of the second candle, and close price lies inside the body of the first (bearish) candle. The resulting candle of the model is also plotted at Figure 1.
For the case if the second candle is doji-like-candle, the model is named "Morning Doji Star".
Fig. 1. "Morning Star" and "Morning Doji Star" candlestick patterns
The identifying of "Morning Star" pattern is implemented in CheckPatternMorningStar() and CheckPatternMorningDoji() methods of class:
The CheckCandlestickPattern(CANDLE_PATTERN_MORNING_STAR) and CheckCandlestickPattern(CANDLE_PATTERN_MORNING_DOJI) methods of class are used to check formation of "Morning Star" and "Morning Doji Star" candlestick patterns.
1.2. Evening Star
This pattern indicates the reversal of uptrend, it consists of three candles (Fig. 2). After a long white candles there is a candle (the color isn't important) with a small body, which lies outside the body of the white candle. The small body of a candle means that strengths of the bulls and bears are equal and market is ready to change the trend.
The third candle of the pattern is the bearish candle, it's body isn't overlapped with the body of the second candle, and close price lies inside the body of the first (bullish) candle. The resulting candle of the model is also plotted at Figure 2.
For the case if the second candle is doji-like-candle, the model is named "Evening Doji Star".
Fig. 2. "Evening Star" and "Evening Doji Star" candlestick patterns
Here are the methods for identifying of "Evening Star" and "Evening Doji Star" patterns:
The CheckCandlestickPattern(CANDLE_PATTERN_EVENING_STAR) and CheckCandlestickPattern(CANDLE_PATTERN_EVENING_DOJI) methods of class are used to check formation of "Evening Star" and "Evening Doji Star" candlestick patterns.
2. Trade signals, confirmed by RSI indicator
The trading signals to open long or short position must be confirmed by indicator. The value of RSI must be lower/greater than critical levels (40 for long position and 60 for short position).
The closing of opened position depends on the values of . It can be done in 2 cases:

if RSI has reached the opposite critical level (70 for long position and 30 for short position)

if the reverse signal isn't confirmed (when RSI reaches the following levels: 30 for long position and 70 for short position)
Fig. 3. "Morning Star" pattern, confirmed by RSI indicator

int CMS_ES_RSI::LongCondition() - checks conditions to open long position (returns 80) and close of the short position (returns 40);

int CMS_ES_RSI::ShortCondition() - checks conditions to open short position (returns 80) and close of the long position (returns 40).
2.1. Open long position/Close short position

The formation of "Morning Star" pattern must be confirmed by indicator: RSI(1)<40 (the value of the RSI of the last completed bar must be less than 40).

The short position must be closed if indicator has crossed upward the critical levels 70 or 30.

2.2. Open short position/Close long position

The formation of "Evening Star" pattern must be confirmed by indicator: RSI(1)>60 (the value of the RSI indicator of the last completed bar must be greater than 60).

The long position must be closed if indicator has crossed downward the critical levels 70 or 30.

2.3. Creating Expert Advisor using MQL5 Wizard
The CMS_ES_RSI class isn't included in the Standard Library classes, to use it, it's necessary to download the acms_es_rsi.mqh file (see attachments) and save it to the client_terminal_data_folder\MQL5\Include\Expert\Signal\MySignals. The same should be done with the candlepatterns.mqh file. You can use it in MQL5 Wizard after restart of the MetaEditor.
To create an Expert Advisor launch :
Fig. 4. Creating Expert Advisor using MQL5 Wizard
Let's specify the name of the Expert Advisor:
Fig. 5. General properties of the Expert Advisor
After that we need to select the modules of trade signals used.
Fig. 6. Signal properties of the Expert Advisor
In our case we use only one module of trade signals.
Adding the "
Signals based on Morning/Evening Stars confirmed by RSI
" module of trading signals:
Fig. 7. Signal properties of the Expert Advisor
Module of trade signals added:
Fig. 8. Signal properties of the Expert Advisor
You can select any trailing properties, but we will use "Trailing Stop not used":
Fig. 9. Trailing properties of the Expert Advisor
Concerning the money management properties, we will use "Trading with fixed trade volume":
Fig. 10. Money management properties of the Expert Advisor
By pressing the "Finish" button, we will get the code of the generated Expert Advisor, located in Expert_AMS_ES_RSI.mq5, it will be saved in terminal_data_folder\MQL5\Experts\.
The default input parameters of the generated Expert Advisor:
must be replaced to:
The Signal_ThresholdOpen/Signal_ThresholdClose input parameters allow to specify threshold levels for open and close of positions.
In code of the LongCondition() and ShortCondition() methods of the trade signals class we have specified the fixed values of the threshold:

Open position: 80;

Close position: 40.
The Expert Advisor, generated by MQL5 Wizard open and close position using the "votes" from the modules of trade signals. The vote of the main module (as container, it consist of all the modules added) is also used, but its LongCondition() and ShortCondition() methods always return 0.
The vote results of the main module is also used in "votes" averaging. In our case we have: main module + 1 module of trade signals, so we need to take this fact into account when setting of the threshold values. Because of this fact the ThresholdOpen and ThresholdClose must be set as 40=(0+80)/2 and 20=(0+40)/2.
The values of Signal_StopLevel and Signal_TakeLevel input parameters is set to 0, it means that closing of the positions will be done only when closing conditions will be true.
2.4. History backtesting results
Let's consider backtesting of the Expert Advisor on historical data (EURUSD H1, testing period: 2010.01.01-2011.03.04, PeriodK=47, PeriodD=9, PeriodSlow=13, MA_period=5).
In creation of Expert Advisor we used the fixed volume (, 0.1), Trailing Stop algorithm is not used ().
Fig. 11. Testing results of the Expert Advisor, based on Morning/Evening Stars + RSI
The best set of input parameters can be found using the of MetaTrader 5 client terminal.
The study of parameters is greatly simplified using the , added starting from 419 build (Fig. 12):
Fig. 12. Balance as a function of PeriodRSI and MA_period input parameters
The code of the Expert Advisor, created by MQL5 Wizard is attached in expert_ms_es_rsi.mq5.
